JTPH-A22 Spring Balancer
The JTPH-A22 Industrial Spring Balancer is an ergonomic material handling solution designed to suspend heavy assembly tools and equipment seamlessly. Featuring an adjustable capacity range of 22kg to 30kg, this tool balancer counteracts the weight of suspended tools, making them feel virtually weightless to operators. It effectively reduces operator fatigue, improves workplace safety, and protects tools from accidental drops or damage on the production line.
|
spring balancer |
|||||||
| Model | Capacity(kg) | Travel (m) | Cable diameter(Фmm) | N.W (kg) | piece/canton | The inside box's size (mm) | The outer canton's size (mm) |
| JTPH-A-3 | 1-3 | 1.5 | 3.2 | 1.5 | 5 | 220*180*75 | 405*235*205 |
| JTPH-A-5 | 3-5 | 1.5 | 3.2 | 1.5 | 5 | 220*180*75 | 405*235*205 |
| JTPH-A-9 | 5-9 | 1.5 | 4.2 | 4.5 | 4 | 245*235*180 | 510*258*395 |
| JTPH-A-15 | 9-15 | 1.5 | 4.2 | 4.5 | 4 | 245*235*180 | 510*258*395 |
| JTPH-A-22 | 15-22 | 1.5 | 5.2 | 8.5 | 1 | / | 388*310*232 |
| JTPH-A-30 | 22-30 | 1.5 | 5.2 | 9 | 1 | / | 388*310*232 |
| JTPH-A-40 | 30-40 | 1.5 | 5.2 | 11.5 | 1 | / | 388*310*232 |
| JTPH-A-50 | 40-50 | 1.5 | 5.2 | 12 | 1 | / | 388*310*232 |
| JTPH-A-60 | 50-60 | 1.5 | 5.2 | 12 | 1 | / | 388*310*232 |
| JTPH-A-70 | 60-70 | 1.5 | 5.2 | 13.5 | 1 | / | 388*310*232 |
| JTPH-A-80 | 70-80 | 1.5 | 5.2 | 13.5 | 1 | / | 388*310*232 |
| JTPH-A-100 | 80-100 | 1.5 | 5.2 | 20.5 | 1 | / | 388*310*232 |
| JTPH-A-120 | 100-120 | 1.5 | 5.2 | 21 | 1 | / | 388*310*232 |
| JTPH-A-140 | 120-140 | 1.5 | 5.2 | 21 | 1 | / | 388*310*232 |
| JTPH-A-160 | 140-160 | 1.5 | 5.2 | 22 | 1 | / | 388*310*232 |
| JTPH-A-180 | 160-180 | 1.5 | 5.2 | 24 | 1 | / | 388*310*232 |
| JTPH-A-200 | 180-200 | 1.5 | 5.2 | 26 | 1 | / | 388*310*232 |
